XPS Insulation Board Manufacturer in Pakistan
Style Styrofoam Industries manufactures and supplies high-quality XPS insulation boards across Pakistan. Our rigid extruded polystyrene boards are designed for roofs, walls, floors, foundations and cold storage, giving contractors, builders and industrial buyers reliable thermal insulation, moisture resistance and long-lasting performance. Custom sizes, bulk supply and nationwide delivery are available.
What Is XPS Insulation Board?
XPS (extruded polystyrene) insulation board is a rigid foam board made through an extrusion process that creates a uniform closed-cell structure. This structure limits heat transfer and keeps water absorption very low, so the board keeps its insulating performance in hot, humid and changing weather. In the local market, XPS board is also commonly known as Jambolon XPS board, and it is one of the most popular insulation choices for rooftops in Pakistan.
How XPS Board Is Manufactured
Polystyrene material is heated, blended and extruded into a continuous board with a closed-cell structure. The boards are then cooled, shaped and cut into the required sizes. Controlled production helps maintain consistent thickness, strength and a smooth finish, which is why extruded boards perform well in demanding construction work.
Common Uses of XPS Insulation Board
- Roof insulation for houses, offices, factories and warehouses
- Wall and floor insulation
- Foundations and basements
- Cold storage and temperature-controlled rooms
- Prefabricated and industrial structures
- New construction and renovation projects
Builders who ask for Jambolon XPS board usually want a lightweight, rigid board that can handle load on roofs and floors while cutting heat gain.
Key Benefits of XPS Board
- Better thermal insulation: reduces heat entering or leaving the building, which can lower cooling and heating costs
- Moisture resistance: closed cells resist water absorption
- High compressive strength: suitable for roofs and floors
- Lightweight and easy to cut: faster, cleaner installation
- Durable: keeps its shape and performance over time
Why Buy XPS Board from Style Styrofoam?
- Direct manufacturer, so no middleman
- Strict quality control
- Custom sizes and bulk orders
- On-time delivery across Pakistan
- Technical advice on the right thickness for your project
Style XPS Board (Extruded Polystyrene Board)
Style XPS Board (Extruded Polystyrene Boards) has highly cross-linked closed cells with common sides and is produced using a fully automated extrusion process in accordance with international specifications and standards. Extruded polystyrene has a high resistance to water absorption. The manufacturing process, combined with the intrinsic qualities of the static component thermoplastic material gives it predictable performance and high insulating value.
It has a 100% closed cell structure and is manufactured in accordance with international standard specifications. Style XPS is the number one choice for home builders, specifier, architects and engineers.
Style XPS Board Technical Specifications
| Item | Testing Method | Unit | Result |
|---|---|---|---|
| Cell Structure | ----- | % | Highly Cross Linked Closed Cell |
| Density* | ASTM-D1622 | kg/m³ | 30 ~ 35 ± 10% |
| Thermal Conductivity 25mm (thickness) | ASTM C-518 KS M 3808-05 | BTU in/ft² hr °F W/mK | 0.118 0.017 |
| R-Value 25.4mm (thickness) | ASTM C-518 KS M 3808-05 | ft² hr °F/BTU in m² K/W | 5.588 0.9891 |
| Compressive Strength | ASTM D1621 | kPa | 320 ~ 410 |
| Coefficient of Linear Thermal Expansion | BS4370 Method 13 | mm/mK | 0.07 |
| Fire Classification* | GB 8624 ASTM C-272 | LOI | B1 28-29.5 |
| Water Absorption by Volume | ASTM C-272 | % by Volume | ≥ 0.18 |
| Size: Length / Width | ----- | mm mm | 1220 - 2440 915 - 1830 |
| Thickness | ----- | mm | 25 ~ 100 ± 5% |
| Edge Profile | ----- | ----- | Butt / Ship Lap Tongue & Groove |
Why Insulate Buildings?
Heating and cooling account for 50 to 70% of the energy used in an average home. Inadequate insulation and air leakage are leading cause of energy waste in most homes.
- Reduce the consumption of electrical energy by up to 40% during the cooling process inside the building.
- Increases the level of comfort for the inhabitants in a building by providing a cooler interior ambience.
- Minimize the usage of air conditioning, helping to reduce the cost of power consumption.
Modes of Heat Transfer
Heat flows naturally from a warmer to a cooler space. In winter, heat moves directly from all heated living spaces to the outdoors and to adjacent unheated attics, garages and basements wherever there is a difference in temperature.
During the summer, heat moves from the outdoors to the interior of the house. To maintain comfort, the heat lost in winter must be replaced by your heating system, and the heat gained in summer must be removed by your air conditioner.
Advantages of Style XPS Board
- Lightweight and easy to handle
- Enhances thermal efficiency, reducing energy cost
- Closed cell extruded polystyrene foam
- Durable and sturdy for long lasting applications
- High thermal resistance
- Strong compressive strength
- Low moisture absorption
- High compressive strength
- Long term retained R-Values
- Environmentally friendly
- High insulation value
- Insulation reduce noise transmission sound
Where Style XPS Board Is Used
Style XPS Board Sizes & Thickness
2 inch - 3 inch
4 inch
Frequently Asked Questions About XPS Board
It is used to insulate roofs, walls, floors, foundations and cold storage rooms to control temperature and save energy. It is lightweight, strong and easy to install in both new and renovation projects.
The price depends on thickness, density, size and order quantity. Many customers search for Jambolon XPS board price in Pakistan, so please request a quote and our team will share a rate for your requirement.
Yes. Its closed-cell structure gives it very low water absorption, so it works well in humid and damp areas. For below-ground use, follow proper installation and waterproofing practices.
Need Style XPS Board for your project?
Call 0300-8887446 | UAN 111-888-808 or request a quote online.
